| CARACTERISTIQUES MATERIELLES | ||||||||||||||||
| Interface | 1× Gigabit Ethernet (RJ-45) Port (supports IEEE802.3at PoE) | |||||||||||||||
| Bouton | Reset | |||||||||||||||
| Alimentation | • 802.3at PoE • 12 V / 1 A DC | |||||||||||||||
| Consommation | • EU: 12.8 W (For PoE); 10.8 W (for DC) • US: 13.9W (For PoE); 11.8 W (for DC) | |||||||||||||||
Dimensions (LxPxH) | 243 × 243 × 64 mm | |||||||||||||||
| Type d’antenne | Internal Omni • 2.4 GHz: 2× 4 dBi • 5 GHz: 2× 5 dBi | |||||||||||||||
| Montage | Ceiling /Wall Mounting (Kits included) | |||||||||||||||
| ADMINISTRATION | |
| Omada App | Yes |
| Administration Centralisée | • Omada Hardware Controller (OC300) • Omada Hardware Controller (OC200) • Omada Software Controller |
| Accès Cloud | Yes (Through OC300, OC200, or Omada Software Controller) |
| Alertes Email | Yes |
| DEL ON/OFF | Yes |
| Administration de contrôle d’accès des adresses MAC | Yes |
| SNMP | v1, v2c, v3 |
| Journal système local/distant | Local/Remote Syslog |
| SSH | Yes |
| Administration par interface WEB | HTTP/HTTPS |
| Administration Niveau 3 | Yes |
| Administration Multi-sites | Yes |
| Administration VLAN | Yes |
| Zero-Touch Provisioning | Yes. Requiring the use of Omada Cloud-Based Controller (Supported by EAP610 V1, V2, V2.2 and above, while is not supported by EAP610 V3) |
| AUTRES | |
| Certification | CE, FCC, RoHS |
| Contenu de l’emballage | • EAP610 • Power Adapter • Ceiling/Wall Mounting Kits • Installation Guide |
| Système requis | Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10, Linux |
| Environnement | • Operating Temperature: 0–40 ℃ • Storage Temperature: -40–70 ℃ • Operating Humidity: 10–90% RH non-condensing • Storage Humidity: 5–90% RH non-condensing |
